| TECHINICAL SPECIFICATION |
| LINE VOLTAGE |
80 V-230V AC Stabilized |
| LINE FREQUENCY |
50 Hz |
| DIMENSIONS (only uroflow module) |
292 mm x 210 mm x 110 mm (L x b x h) |
| REPEAT COPY |
Selectable in two modes - 5ml / 10ml per sec. |
| ACCURACY |
± 5% of voided volume in reading
± 2% of voided volume at full range |
| Maximum Capacity for a single micturation |
2000 ml. |
| Maximum peak flow rate detectable |
50 ml/sec. |
| Maximum micturation times |
Normal : 50 seconds
Extended : 300 seconds |
| Maximum detectable
"Time to Max Flow" |
1 second |
| PARAMETERS MEASURED |
Voided volume, voiding time, flow time, max. flow rate, time to max. flow, avg. flow rate and hesitancy |
| STANDARD ACCESSORIES |
Advance Microprocessor based Ad-On module, Transducer, Micturation chair with back rest and arms, Urine collection beaker and EPSON Compatible Dot matrix Printer |
| PRINTER |
Supports to WIPRO/EPSON Compatible Dot matrix printer |
